GAMEMAX 4U Rackmount AI Workstation Chassis | SSI‑EEB E‑ATX Compatible | 360mm Water‑Cooling Support | 7 PCI Expansion Slots | SPCC 1.0/1.2mm Steel Server Case
• Wide Motherboard Compatibility: Supports SSI‑EEB, SSI‑CEB, E‑ATX down to Mini‑ITX for AI workstation & server.
• Robust SPCC Build: 1.0/1.2mm SPCC steel with eco‑friendly black spray finish for rack‑mount long‑term operation.
• Mixed‑Storage Design: 2×3.5 HDD + 3×2.5 SSD internal bays for flexible storage expansion.
• Strong Cooling Performance: Pre‑installed fans, front‑mount 360mm radiator support for high‑power AI computing.
• High‑Expansion Design: 420mm max GPU length, 152mm CPU cooler height, 7 PCI slots, rich front‑panel I/O & LED indicators.
• Rack‑Ready Structure: 30kg load‑rated slide rail compatible, front dust filter, ATX PS2 PSU supported.
| Case Type | AI Workstation（4U Rackmount） | |
| Color(s) | Black | |
| Materials | SPCC 1.0/1.2mm，Surface Environmentally Friendly Black Spraying Process | |
| M/B Compatibility | SSI-EEB、SSI-CEB、E-ATX、ATX、M-ATX、Mini ITX | |
| PSU Compatibility | ATX PS2 | |
| Side Panel | Front Panel | Metal Cover |
| Left/Right | Metal Cover | |
| External Drive Bay(s) | 5.25" (ODD) | N/A |
| 3.5" | N/A | |
| Internal Drive Bay(s) | 3.5" (HDD) | 3.5"HDD*2+2.5SSD*3 |
| 2.5" (SSD) | ||
| I/O Ports | Power Button | *1 |
| Reset Button | *1 | |
| USB3.2 Gen1 Type A Port(s) | *2 | |
| USB3.2 Gen2 Type C Port(s) | *1 | |
| LED Indicators | Power Status x 1, HDD Activity x 1 | |
| LAN Activity x 2 | ||
| Cooling Fan Support (Fan Size) | Front | 3x120mm (FN12-B1 Pre-installed)，Fan reverse lock |
| Top | / | |
| Rear | 2x80mm (8025 Dual Ball Bearing Fan Pre-installed) | |
| Bottom | / | |
| Water Cooling Support (Radiator Size) | Front | 360*1 |
| Bottom | / | |
| MB | / | |
| Slide Rail | Rated load capacity: 30Kg. Length: 50CM, can extend up to 1M. Standard rack supports 1U to 4U.(without Rail kit) | |
| Foot pad | ABS plastic，2 individually packaged units | |
| Dust Filters | Front With Dust Filter | |
| PCI Expansion Slots | *7 | |
| Carton & Logo | GAMEMAX | |
| Dimensions | Chassis | (L)445*(W)426*(H)177mm |
| Full Case (inc Fascia) | (L)480*(W)482*(H)177mm | |
| Package | (L)562*(W)543*(H)260mm | |
| Net Weight (Kg) | kgs | |
| Gross Weight (Kg) | kgs | |
| GPU Length | Up to<420mm | |
| CPU Cooler Height | Up to 132mm(With GPU Holder) Up to 152mm(W/O GPU Holder) | |
| Cable Management Depth | Up to 35mm | |
