4U Rackmount Server Case | 8 HDD Large Storage | 7 PCI Expansion Slots | SGCC Heavy Duty Steel Chassis
• Wide Compatibility: Supports ATX/M-ATX/Mini ITX motherboards and ATX PS2 power supply.
• Ample Storage: 8×3.5 HDD + 2×2.5 SSD bays, 2×5.25 ODD + 1×3.5 external bays.
• Sturdy Build: SGCC 0.8mm steel, black painted interior, durable and stable.
• Heat Dissipation and Dust Prevention: The front panel is pre-installed with 1 PWM fan (model FN12-B1-R)
• The rear panel is pre-installed with 2 PWM ball-bearing fans (80mm specification), along with a front dust filter.
• Practical Design: 7 expansion slots, up to 270mm VGA card, USB3.2 ports, security lock.
| Case Type | AI Workstation（4U Rackmount） | |
| Color(s) | Black | |
| Materials | SGCC 1.0/0.8mm，Black painting interior | |
| M/B Compatibility | ATX、M-ATX、Mini ITX | |
| PSU Compatibility | ATX PS2 | |
| Side Panel | Front Panel | Metal Cover |
| Left/Right | Metal Cover | |
| External Drive Bay(s) | 5.25" (ODD) | *2 |
| 3.5" | *1 | |
| Internal Drive Bay(s) | 3.5" (HDD) | 3.5"HDD*8+2.5SSD*2 |
| 2.5" (SSD) | ||
| I/O Ports | Button | *2 |
| USB3.2 Gen1 Type A Port(s) | *2 | |
| LED Indicators | Power Status x 1, HDD Activity x 1 | |
| Cooling Fan Support (Fan Size) | Front | 1x120mm (FN12-B1 Pre-installed)，Fan reverse lock |
| Top | / | |
| Rear | 2x80mm (8025 Dual Ball Bearing Fan Pre-installed) | |
| Bottom | / | |
|
Water Cooling Support (Radiator Size) |
Front | / |
| Bottom | / | |
| MB | / | |
| Slide Rail | Rated load capacity: 30Kg. Length: 50CM, can extend up to 1M. Standard rack supports 1U to 4U.(without Rail kit) | |
| Foot pad | ABS plastic，2 individually packaged units | |
| Security | Pad lock, Chassis Instrusion | |
| Dust Filters | Front With Dust Filter | |
| PCI Expansion Slots | *7 | |
| Carton & Logo | GAMEMAX | |
| Dimensions | Chassis | (L)446*(W)427*(H)177mm |
| Full Case (inc Fascia) | (L)483*(W)476*(H)177mm | |
| Package | (L)562*(W)543*(H)260mm | |
| Net Weight (Kg) | kgs | |
| Gross Weight (Kg) | kgs | |
| GPU Length | Up to<270mm | |
| CPU Cooler Height |
Up to 120mm(With GPU Holder) Up to 145mm(W/O GPU Holder) |
|
| Cable Management Depth | Up to 35mm | |
