• Ultra-large Size for Efficient Heat Dissipation: With a specification of 200x200x25mm, a rotational speed of 800±200RPM, and a large air volume of 38.6CFM, it can quickly expel the heat inside the PC case.
• Long-lasting Sleeve Bearing: Equipped with a sleeve bearing, it has a service life of up to 40,000 hours in an environment of 25℃/95% RH, ensuring stable and reliable operation.
• Quiet Operation: The running noise is only 29.5dB, which is low and unobtrusive, making it suitable for various scenarios.
• Wide Voltage Adaptability: It supports a voltage range of 5.0 - 13.8V, with a rated voltage of 12V and a starting voltage of 5.0V, featuring strong compatibility.
Item | Unit | Specification | Condition |
Out dimension | mm | 200*200*25mm | NO |
Bearing system | ------- | Sleeve Bearing | NO |
Rated voltage | V DC | 12V | NO |
Voltage range | V DC | 5.0-13.8V | NO |
Start-up voltage | V DC | 5.0V | ON/OFF |
Rated Current | A | 0.22A | At rated voltage |
Worked Current | A | 0.15+0.02A | At rated voltage |
Locked current | A | 0 | Rotor Locked |
Rated power | W | 2.62W | At rated voltage |
Speed | RPM | 800±200RPM | After five minutes |
Air Flow | CFM | 38.6 | In free Air |
Static Air Pressure | mm-H2O | 0.75 | At 0 CFM |
Noise level | dB | 29.5 | At Normal Speed |
Motor Protection | ------ | By Impedance | NO |
Other Features | FG Output | No | NO |
Auto restart | No | NO | |
Lock Rotor Alarm | No | NO | |
Temperature Control | No | NO | |
Cable | Lead Wire | UL1007#26AWG | NO |
Connection Lead Type | 470mm | NO | |
Connector | ------ | 25.4-3P | NO |
Life Expectancy | Hours | 40,000 | 25℃/95%RH |
Net Weight | Gram | ---- | ---- |
Packing | pcs/Carton | ---- | ---- |
NO-of Blade | Four Rotor | ---- | ---- |
Rotating Direction | Counter-Clockwise | ---- | ---- |
