GameMax GX-850 Modular,80+ Gold ATX Power supply, One of the innovative Gold design basis on Platinum Level, LLC and DC-DC circuit.
• The classic efficiency over 92%, The free-cable technology featured
• GameMax GX series power supply 80+ Gold certified that offers great value to gamers and system builders
• FDB Fan reduces heat during heavy load while keeping the noise level down, Designed with stability and durability, GX Series is the perfect choice to power your systemsLLC+DC--DC high-efficiency 80+ Gold APFC Certified
• DC-DC integrated energy storage inductor, quiet and highly efficient100-240Vac full voltage input
• Multiple PCIE interfaces fully support the latest graphics cardsIntegrated all solid capacitor, Free-Cable module output, lower loss powerFarad resonance capacitor is stable and efficient
• 105℃ mainstream capacitor has long life and smooth output
• The temperature-controlled fan is extremely quiet
• Total SEVEN levels of protection, OTP, OCP, SCP, OVP, UVP, OPP, SIP
• All black flat pure copper output line, efficient and powerful
• Components by SMT produced, Quick heat dissipation and more stable
Detailed Specifications
Dimensions: | 150mm x 85mm x 140mm (W x H x D) |
Input Voltage: | 100-240 VAC |
Input Current: | 10-5A |
Input Frequency Range: | 50-60Hz |
PFC: | Active PFC (>.99) |
Power Good Signal: | 100-150 ms |
Hold Up Time: | >10ms |
Efficiency: | > 87% (92% max) |
MTBF: | > 100,000 Hours |
Protection: | OVP / UVP/ SIP / OCP/ OLP/ OPP/ SCP/OTP |
Power: | 850W |
Operation Temperature: | 0-40C |
Safety: | CE / FCC / CB/TUV/cTUVus |
Cooling: | 120mm Ultra Silent Fan |
Noise: | <25dBa |
80 Plus Certified: | Yes - 80 Plus Gold |
