● RGB Lighting
RGB LED Lighting to power your system with style.
Bring your system to life with build-in unique lighting effects that without additional controlled used
● SEMI-Modular Design
Increased expansion for addtional modular socket of PCIe and SATA/Molex
There is 4pcs connector for make user more flexiable once they need to connect more devices.
● 80PLUS APFC Ready!
80-82% efficiency @ 20-100% load. Compliant with 80PLUS efficiency requirements.
● Lot 6 2013 ready!
Help system meet ErP Lot 6 2013 (<0.5W at standby mode) with high efficiency 5Vsb circuitry.
● AirGuard
Honeycomb ventilation design for optimal heat dissipation.
● Durable hydraulic pressure bearing fan
Low Noise 12cm Fan with intelligent fan speed control.
The intelligent thermal circuit feature is designed to find the optimal balance between the necessity to cool the components and the need to run the power supply in the most silent manner possible.
● Smart and Silent Fan control
There is a ECO switch at the back of the power supply which allows users to customize their cooling needs by selecting between the Fanless Mode and the Silent Mode
ECO -ON Status, Fanless Mode
ECO -OFF Status, Silent Mode
●Tempreature control curve
Reduced noise without increase in
temperature;
Extended fan life due to the reduced
number of fan rotations;
Optimized heat dissipation at all times;
Unsurpassed silent performance in Fanless
Mode.
VP-500-M-RGB
Technical Specifications | ||
80PLUS? | APFC 80+ Plus Compliant | |
Efficiency Level | >80% | |
Noise Level | Zero (ECO-ON),<32dBA (at 100% load) | |
Form Factor | Intel ATX 12 V 2.31 | |
Dimensions | 140 mm (W) x 150 mm (L) x 86 mm (H) | |
Fan Information | Fan Size | 120 mm |
Fan Control | ECO-ON/OFF | |
Fan Bearing | Fluid Dynamic Bearing | |
Life Expectancy | 50,000 hours at 40 °C, 15 % - 65 % RH | |
Cable Information | Modularity | Wired Cabling |
Cable type | Black tube shield along with colors CPU and PCIe connecor | |
Electrical Features | Operating Temperature | 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C) |
MTBF @ 25 °C, excl. fan | 100,000 hours | |
AC Input | Full Range AC input (100-240Vac) | |
Protection | OPP, OVP, UVP, OCP, OTP, SCP | |
Safety and Environmental | Safety and EMC | CB, CCC,CE |
Environmental Compliance | RoHS, WEEE, ErP Lot 6 |
PSU SPECIFICATION
AC INPUT: AC 100-240V 50-60Hz 8-4A | |||||
DC Voltage | +3.3V | +5V | +12V | -12V | +5VSB |
Output | 15A | 15A | 34A | 0.5A | 2.5A |
Watt | 100W | 408W | 6W | 12.5 W | |
Max Output | 500W |
