Gamemax Titan Silent M905S Black full tower PC Case with a powerful cooling system, with 3x12cm silent fans pre-installed which speed of the fan can be controlled via the top button
• The fan speed can be freely controlled and it is with HD Audio, 2 x USB 2.0 2 x USB 3.0 located on the top giving the user easy access
• The Titan Silent M905S also supports E-ATX big size motherboard board as a PC server tower, and important that the Master case can install a total of 10 x HDDs to make your PC in Raid 3 or Raid 5 (Redundant Arrays of Independent Drives)
• Rolled edges ensure safety and with total 8+2 sets of tool-free HDD easy to assemble, an additional 2x SSD on the back of the motherboard
• Supports 430mm VGA card and 165mm height of CPU cooler.
| Form Factor (Midi, Micro, Mini ITX, Full) | Full Tower | |
| Chassis | SPCC 0.8mm, Black painting interior | |
| PSU Form Factor | Bottom/ATX | |
| M/B Form Factor | ATX、M-ATX、ITX, EATX(272*305mm) | |
| Front Panel | Elegant matte finish with mesh | |
| Top Panel | With mesh for better heat disspation | |
| Branding | Box | GAMEMAX |
| Unit | 1 | |
| Side Panel | Left | Big window side panel |
| Right | Metal | |
| External Drive Bay(s) | 5.25" (ODD) | *3 |
| 3.5" | *0 | |
| Internal Drive Bay(s) | 3.5" (HDD) | *8 |
| 2.5" (SSD) | *10 (exchangeable) | |
| I/O SPEC | Buttons | *2 |
| USB2.0 Port(s) | *2 | |
| USB3.0 Port(s) | *2 | |
| USB3.1 Port(s) | *0 | |
| HD Audio Support | *1 | |
| Card Reader (Support) | *0 | |
| Fan Controller | *2 | |
| RGB Controller | *0 | |
| Controller max. fans | *6 | |
| RGB controller | *0 | |
| Cooling Fan Support | Front | 2x12cm Black silent fan (Included) |
| Top | None | |
| Rear | 1x12cm Black silent fan (included) | |
| Bottom | 1*12cm (Fan optional) | |
| Left Side | 0 | |
| PSU Cover | *1 | |
| Water Cooling Support (Radiator Size) | Front | Support 240/360mm water cooling |
| Top | Support 240/360mm water cooling | |
| Rear | Support 120mm water cooling | |
| Dust filter | Bottom cover with dust filter (2*pieces) | |
| Slots | *8 | |
| Carton Logo | GAMEMAX | |
| Dimensions | Chassis | (L)470*(W)210*(H)465mm |
| Full Case (inc Fascia) | (L)520*(W)212*（H)488mm | |
| Carton | (L)540*(W)286*(H)597mm | |
| VGA Card Length | 420mm | |
| CPU Cooler Height | 170mm | |
| Cable Management Depth | 25mm | |
| Weight | Net Weight (Kg) | 8.7 kgs |
| Gross Weight (Kg) | 9.8 kgs | |
Key Features
Case Type - Midi tower high-end gaming case
Chassis Thickness- made by 0,8mm steel
MB Type- E-ATX/ATX/mATX/ITX
Cooling System - Supports 240mm front and 360mm Top water cooling radiator
Max.VGA Card (Length) - 430mm
Max.CPU Cooler (Height) - 165mm
Support Cable Management - 21mm
I/O Port - HD Audio, 2 x USB 2.0 2 x USB 3.0
Tool-Free- 2x(3.5 or 2.5)HDD tool free brackets+2x2.5 extra cage
Side Window - Outstanding side window
Fan controller - 2 x Fan controllers each supporting up to 3 x fans (3 pin connector)
Vent Filters - Removable filter for PSU vent at the bottom and a magnetic vent filter at the side
Fans - 3 x 12cm LEDs fans on the front and rear (Included)
The fan per-installed- 2x12cm blue LED fan on frontm and 1x12cm blue LED fan on rear
NW/GW-8.5kg/9.5kg
Chassis Size-510*210*530mm
Packing Size-579*286*597mm
