GameMax FN12A-S2I-R, Reverse 120mm Black frame ARGB Fan-Reverse Fan Blade for Power Supply Shroud /Bottom plate of Case for Air Intakes!
• Infinity mirror look all around.
• 120mm full function ARGB PWM fan
• The intelligent temperature controls the speed at 800~1600±10% RPM, by linking to the motherboard PWM 4pin socket, so the fan speed auto controlled and keeps the fans quiet.
• Embedded magnetic Fluid Dynamic Bearing to provide stability, durability, and longevity.
• 24 LEDs in each fan，Center 8pcs, Outer ringg 16pcs.
• 【Reverse Blade of Fan】 Reverse Fan Blade for Power Supply Shroud /Bottom plate of Case for Air Intakes, to additional increase airflow from bottom to vertical chassis design type.
Specification
| Dimensions: | 120 x 120 x 25mm |
| Fan Frame Colour: | Black |
| Fan Blades / Colour: | 9 Reverse Fan Blade / Semi-transparent black |
| LED Qty / Type: | Center 8pcs, Outer ring 16pcs |
| Bearing Type: | Hydraulic Bearing |
| Fan Speed: | 800-1600 RPM ± 10% |
| Max. Air Flow : | 44.35 CFM ± 10% |
| Max. Static Air Pressure : | 1.42mm - H2O |
| Noise Level (max.): | 31.21db(A) |
| Cable Length : | 4pin(M/F) PWM Power / 3pin Aura(M/F)500/500mm |
| Accessories: | Screws |
| Connectors: | 4pin(M/F) PWM Power / 3pin Aura(M/F) |
| Rated Voltage: | 12V |
| Rated Current (max.): | 0.15A (Max. 0.18A) |
| Rated Input Power: | 1.8W (Max. 2.16W) |
| Test Voltage: | 5-13.8V |
| Start Voltage: | 5V |
| M.T.B.F.: | 30,000 hrs |
General Specifications
| Manufacturer Part Number: | FN12A-S2I-R |
| EAN Number: | 6931858791373 |
| Has Mains Plug: | |
| Colour: | Black |
| What's In The Box: | Fan x1 Screws x4 Long Screws x4 |
| Unit (Product) Dimensions (mm): | 120mm x 120mm x 25mm (W x H x D) |
| Packaging Dimensions (mm): | 123mm x 140mm x 27mm (W x H x D) |
| Net Weight (KGs): | |
| Gross Weight (KGs): |
