5Pcs HDT copper sintered powder heatpipes makes sure high-efficiency
• heat conducts 2.5mm fin pitch high penetrability tower heatsink dissipates heat with low speed noise fan, Intel Gen10th CPU Mate
Features
5Pcs HDT copper sintered powder heatpipes makes sure high-efficiency heat conducts
2.5mm fin pitch high penetrability tower heatsink dissipates heat with low speed noise fan.
125X125X25 PWM Green LED silent fan detachable when cleaning need.
Simple and Friendly installation in Intel and AMD system without moving the motherboard.
Specification
Application For:
Intel/AMD TDP 187W CPU.
Intel LGA775/LGA1155/LGA1150/LGA1156/LGA1151/LGA1200
AMD Socket 754/939/940/AM2/AM2+/AM3/AM3+/FM1/FM2/AM4
Technical Spec:
Overall Dimension: 126(L)X85(W)X148(H)mm
Fan Dimension: 120X120X25mm
Net Weight: 575g
Bearing Type: Rifle Bearing
Rated Voltage: 12VDC
Operating Voltage: 7~13.5VDC
Started Voltage: 5VDC
Rated Current: 0.15±10%A
Power Input： 2.04W
Fan Speed： 800~1800±10%RPM
Max. Air Flow: 27.96~52.54±10%CFM
Noise: 18~30.5dBA±10%
Lifetime: 30,000Hours
Product Drawing:
